10A Solar Regulator
Regular price
$107.40
Sale price
$107.40
Regular price
Unit price
Check in-store availability
Description
Product Details
For smaller fixed solar setups, the REDARC 10A Solar Regulator (SRP0120) regulates power from 12V or 24V panels to the right voltage for your house or auxiliary batteries. It can charge two separate battery banks from one panel array.
The regulator has a 10A current rating, multi-stage charging and a maximum charging voltage of 14.8V / 29.6V. Standby current is under 4mA, and LED indication keeps you informed. It is designed primarily for REDARC's SMR range of fixed solar panels; add the Anderson™ to bare wire cable (SRC0016) to use it with REDARC solar blankets and folding panels. The battery setting defaults to AGM. To change battery types and configuration, REDARC recommends the Solar Remote Monitor (SRP0240-RM). It is not compatible with Lithium (LiFePO4) batteries.
Key features:
• Charges up to two battery banks
• 10A rating for 12V or 24V systems
• Multi-stage charging with LED indication
• Optional remote monitor and remote temperature sensor
Backed by a 2-year REDARC warranty. Talk to The 4x4 Store if you are unsure whether 10A or 20A suits your panels.
The regulator has a 10A current rating, multi-stage charging and a maximum charging voltage of 14.8V / 29.6V. Standby current is under 4mA, and LED indication keeps you informed. It is designed primarily for REDARC's SMR range of fixed solar panels; add the Anderson™ to bare wire cable (SRC0016) to use it with REDARC solar blankets and folding panels. The battery setting defaults to AGM. To change battery types and configuration, REDARC recommends the Solar Remote Monitor (SRP0240-RM). It is not compatible with Lithium (LiFePO4) batteries.
Key features:
• Charges up to two battery banks
• 10A rating for 12V or 24V systems
• Multi-stage charging with LED indication
• Optional remote monitor and remote temperature sensor
Backed by a 2-year REDARC warranty. Talk to The 4x4 Store if you are unsure whether 10A or 20A suits your panels.
| Category | Solar Regulator |
|---|
